#include "client.h"
#include <math.h>
#include <gtk/gtk.h>
#include "image.h"
#include "main.h"
#include "mapdata.h"
#include "gtk2proto.h"

Include dependency graph for map.c:

Functions
static void	coord_to_tile (int x, int y, int dx, int dy)
	Given x, y coordinates on the map drawing area, determine the tile that the coordinates are on with respect to the player. More...

void	display_map_doneupdate (int redraw, int notice)
	This is called after the map has been all digested. More...

int	display_mapscroll (int dx, int dy)

static void	draw_darkness (cairo_t *cr, int nx, int ny, int mx_start, int my_start)

void	draw_map ()
	Draw the map window using the appropriate backend. More...

static void	draw_move_to (cairo_t *cr, int mx_start, int my_start)

static void	draw_pixmap (cairo_t cr, PixmapInfo pixmap, int ax, int ay)
	Draw a pixmap to the given map tile on screen. More...

static void	draw_smooth_pixmap (cairo_t cr, PixmapInfo pixmap, const int sx, const int sy, const int dx, const int dy)

static void	drawsmooth (cairo_t *cr, int mx, int my, int layer, int picx, int picy)
	Draw anything in adjacent squares that could smooth on given square. More...

static void	gtk_map_redraw ()
	Redraw the entire map using GTK. More...

static gboolean	map_button_event (GtkWidget widget, GdkEventButton event, gpointer user_data)
	Handle a mouse event in the drawing area. More...

void	map_check_resize ()
	Calculate and set desired map size based on map window size. More...

static void	map_draw_labels (cairo_t *cr, int mx_start, int nx, int my_start, int ny)

static void	map_draw_layer (cairo_t *cr, int layer, int mx_start, int nx, int my_start, int ny)
	Draw a single map layer to the given cairo context. More...

static gboolean	map_expose_event (GtkWidget widget, GdkEventExpose event, gpointer user_data)

void	map_init (GtkWidget *window_root)
	This initializes the stuff we need for the map. More...

static double	mapcell_darkness (int mx, int my)

int	relative_direction (int dx, int dy)
	Given a relative tile coordinate, determine its compass direction. More...

void	resize_map_window (int x, int y)
	Resize_map_window is a NOOP for the time being - not sure if it will in fact need to do something, since there are scrollbars for the map window now. More...

static void	update_global_offset ()

Variables
static GtkWidget *	map_drawing_area

int	map_image_size = DEFAULT_IMAGE_SIZE

GtkWidget *	map_notebook

static gboolean	map_updated = FALSE

int	predict_alpha
	Speed of local map prediction scrolling, 0-100 (0 to disable). More...

bool	time_map_redraw

Detailed Description

Initializes and renders the map drawing area. Handles map drawing area events, notably the "click to look at" mouse event.

Definition in file map.c.

Function Documentation

◆ coord_to_tile()

static void coord_to_tile	(	int	x,
		int	y,
		int *	dx,
		int *	dy
	)

static

Given x, y coordinates on the map drawing area, determine the tile that the coordinates are on with respect to the player.

Clicking on the tile with the player returns (0, 0).

Definition at line 589 of file map.c.

References CONFIG_MAPHEIGHT, CONFIG_MAPSCALE, CONFIG_MAPWIDTH, map_drawing_area, map_image_size, and use_config.

Referenced by map_button_event().

Here is the caller graph for this function:

◆ display_map_doneupdate()

void display_map_doneupdate	(	int	redraw,
		int	notice
	)

This is called after the map has been all digested.

this should perhaps be removed, and left to being done from from the main event loop.

Parameters

redraw	If set, force redraw of all tiles.
notice	If set, another call will follow soon.

Definition at line 671 of file map.c.

References map_updated, and redraw().

Referenced by Map2Cmd(), map_scrollCmd(), and MapExtendedCmd().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ display_mapscroll()

int display_mapscroll	(	int	dx,
		int	dy
	)

Definition at line 155 of file map.c.

Referenced by mapdata_scroll().

Here is the caller graph for this function:

◆ draw_darkness()

static void draw_darkness	(	cairo_t *	cr,
		int	nx,
		int	ny,
		int	mx_start,
		int	my_start
	)

static

Create light map nx wide, ny tall. Add a border 1px around to get rid of edge effects.

Definition at line 364 of file map.c.

References CFG_LT_PIXEL, CFG_LT_PIXEL_BEST, CFG_LT_TILE, CONFIG_LIGHTING, map_image_size, mapcell_darkness(), MIN, and use_config.

Referenced by gtk_map_redraw().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ draw_map()

void draw_map ( )

Draw the map window using the appropriate backend.

Definition at line 525 of file map.c.

References CONFIG_MAPSCALE, gtk_map_redraw(), LOG(), LOG_DEBUG, map_check_resize(), MIN, time_map_redraw, update_global_offset(), and use_config.

Referenced by map_expose_event(), and redraw().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ draw_move_to()

static void draw_move_to	(	cairo_t *	cr,
		int	mx_start,
		int	my_start
	)

static

Definition at line 411 of file map.c.

References is_at_moveto(), map_image_size, move_to_attack, move_to_x, and move_to_y.

Referenced by gtk_map_redraw().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ draw_pixmap()

static void draw_pixmap	(	cairo_t *	cr,
		PixmapInfo *	pixmap,
		int	ax,
		int	ay
	)

static

Draw a pixmap to the given map tile on screen.

Parameters

ax	Map cell on-screen x-coordinate
ay	Map cell on-screen y-coordinate

Definition at line 137 of file map.c.

References PixmapInfo::map_image, and map_image_size.

Referenced by map_draw_layer().

Here is the caller graph for this function:

◆ draw_smooth_pixmap()

static void draw_smooth_pixmap	(	cairo_t *	cr,
		PixmapInfo *	pixmap,
		const int	sx,
		const int	sy,
		const int	dx,
		const int	dy
	)

static

Definition at line 144 of file map.c.

References PixmapInfo::map_image, and map_image_size.

Referenced by drawsmooth().

Here is the caller graph for this function:

◆ drawsmooth()

static void drawsmooth	(	cairo_t *	cr,
		int	mx,
		int	my,
		int	layer,
		int	picx,
		int	picy
	)

static

Draw anything in adjacent squares that could smooth on given square.

Parameters

mx
my	Square to smooth on. You should not call this function to smooth on a 'completely black' square.
layer	Layer to examine (we smooth only one layer at a time)
picx
picy	Place on the map_drawing_area->window to draw

Definition at line 169 of file map.c.

References draw_smooth_pixmap(), MapCellLayer::face, MapCell::heads, mapdata_can_smooth(), mapdata_cell(), mapdata_contains(), pixmaps, MapCell::smooth, and PixmapInfo::smooth_face.

Referenced by map_draw_layer().

Here is the call graph for this function:
